SEMI AUTOMATIC GI SHEET CUTTING LINE (CTL)
- Model No: CTLM-1219
- Category: Machinery
- Keywords: CUT TO LENGTH MACHINE, SHEARING LINE, SHEARING MACHINE, SHEET CUTTING LINE, SHEET CUTTER, AUTOMATIC CTL, AUTOMATIC CUTTING LINE, CORRUGATED SHEETS, CORRUGATION MACHINES, GALVANIZED SHEETS.
- Manufacturer Name: B.S. Engineering Co.
- Packing size:
- Price: NA
Description
General specifications : INPUT MATERIAL : G.I. COIL COIL WT. : 5,000 KGS. COIL WIDTH : 750 MM. – 1,219 MM. SHEET THICKNESS 0.10 MM. – 0.50 MM. COIL BORE : 508MM. CUTTING LENGTH : 4,270 MM.(MAX.) PACKING WT. : 2.5 TON List of Machinery : DECOILER SHAFT PINCH ROLL ASSLY FEEDING ROLL ASSLY WITH A.C. DRIVE SHEAR WITH CLUTCH BRAKE MOTOR PILING TABLE AIR COMPRESSOR ELECTRICAL CONTROL PANEL NO. OF SHEETS PER MIN. 18 - 20 PCS. X 1,830 MM. LONG LENGTH TOLERANCE ± 1.0 MM.
