TRANSMISSION LINE TRAINER
  • Model No: TXL1P02
  • Category: Electrical Engineering
  • Keywords: ELECTRICAL TRANSMISSION LINE TRAINER
  • Manufacturer Name: CALTEK
  • Packing size: 4FEET X2FEET X4FEET
  • Price: ₹1

Description

This is our custom item for the study of 1 phase transmission line behavior & parameter like actual system. Above is 1ph kit. MODBUS RS485 interface for PC & software to observe online at a time 15 parameters of transmission line in value & graph. In kit, 1 multi-function meter also provided to see any 3 parameter out of 15 at a time just by scrolling. TRANSMISSION LINE TRAINER CONSIST OF:- 100 KM X 3 SIMULATED 1 PHASE TX LINE BLOCK AT THE END OF EACH BLOCK SHORT IS POSSIBLE ALL DIGITAL METERS AT the RECEIVING END, MICROPROCESSOR CONTROLLED MULTI FUNCTION MULTI-DISPLAY UNIT WITH RS485 & USB INTERFACE, FOR AT A TIME 15 PARAMETER DISPLAY ON PC. Parameters:- Phase Voltage (L-L,L-N), Phase Current, Frequency, Phase Power factor, Phase angle, Phase Active, Reactive and Apparent Power, Apparent Energy (kVAh), Active energy (kWh) Import and Export, Reactive Energy (kVArh) Import and Export, System Voltage & System Current, kVA,kVAr and kW, Neutral Current, Current Demand and Max Current Demand, kVA Demand and Max. etc. LOADING PROVISION FOR 1KVA – INDUCTIVE, CAPACITIVE & RESISTIVE. 0.5 & 1 KVAR CAPACITOR BANK ABCD PARAMETER MEASUREMENT. FERRANTI EFFECT AT END POINTS AT NO LOAD. BACK LIGHT ILLUMINATED MOP SHEET PANEL. HIGH QUALITY PATCH CORD. ON LINE PC SOFTWARE FREE. ## LAPTOP WITH W10 INCLUDED.
