4 Digital, Analog Input And 4 Digital Output With Modbus RS485|WIN-IO-4DDAI
- Model No: WIN-IO-4DDAI
- Category: Circuit Boards
- Keywords: 4DO 4DI 4AI Module, Relay Output IO, 10A 230V Relay Module, 4–30V Digital Input, 4–20mA AI Module, 0–10V Analog Module, NTC Type 3 10k Input, Modbus RTU IO, 10-bit/12-bit Analog Input, Industrial Automation IO, Mixed IO Module.
- Manufacturer Name:
- Packing size:
- Price: ₹6,111
Description
This multifunction IO module features 4 Relay-Based Digital Outputs (10A / 230V), 4 Digital Inputs (4–30V DC), and 4 Analog Inputs supporting 4–20mA, 0–20mA, 0–5V, and 0–10V. The Analog Inputs offer 10-bit or optional 12-bit resolution, along with a jumper-selectable NTC Type 3 10k mode for temperature sensing. It communicates via Modbus RTU (RS485) and includes DIP switch configuration for Slave ID and Baud Rate setup. A compact and reliable choice for automation, monitoring, HVAC, and process control applications.
